The 32nd China International Exhibition on Packaging Machinery and Materials

Anti-corrosion filling machine

Main technical parameters: 1. Production capacity: ≤3,500 bottles/hour; 2. Compatible bottle dimensions: Φ40–120 mm, bottle height 60–320 mm; 3. Metering accuracy: ±1% (based on 100 ml); 4. Air supply pressure: 0.6–0.8 MPa; 5. Power supply: 380 V, 50 Hz; 6. Power consumption: 1 kW; 7. Air consumption: 200 L/min; 8. Main unit external dimensions: 2,000 × 1,030 × 2,300 mm (length × width × height); 9. Overall machine weight: approximately 850 kg.

Follow‑along canning machine

Technical Specifications: 1. Bottle capacity: 300–2000 ml 2. Average production rate: 70–80 bottles per minute 3. Average hourly output: 4,500 bottles 4. Average daily output (based on 10 hours): 45,000 bottles 5. Average daily output per line: 45,000 bottles 6. Air supply pressure: 0.5–0.8 MPa 7. Total electrical power consumption: 8 kW

Follow‑along capping machine

Technical Specifications: 1. Production Capacity: ≤1,800 bottles/hour; 2. Pass Rate: ≥99%; 3. Applicable Bottle Types: - Round Bottles: Diameter 50–140 mm, Height 230–340 mm; - Square Bottles: Length 45–250 mm, Width 45–140 mm, Height 90–340 mm; 4. Cap Specifications: Diameter 30–65 mm, Height 15–30 mm; 5. Air Supply Pressure: 0.6–0.8 MPa; 6. Power Supply: 380 V, 50 Hz; 7. Power Consumption: 2.5 kW; 8. Weight: 800 kg; 9. Overall Dimensions: 3,300 × 1,200 × 2,300 mm (Length × Width × Height) (including cap sorter).
