SIDE LABELING MACHINE

This machine is suitable for flat bottles, square bottles, round bottles and other bottles in food, medicine, daily chemical and chemical industries.
For example: cereal, chili sauce, plum, honey, wine, wind oil essence, shampoo, Shower Gel and so on.
 This machine can be use as single side， double sides labeling or round bottle circle labeling, suitable for flat bottle, square bottle two-sided or one-sided labeling and round bottle circle labeling.
 Multidimensional adjustment of labeling module and special design of shaping belt mechanism ensure accurate positioning of flat bottle, square bottle and irregular surface products, and improve labeling accuracy.
 Elastic belt design to improve the stability of bottle conveying and ensure higher labeling accuracy.
 Synchronizer is used to track and detect the position of the product to be pasted automatically to achieve accurate labeling.
 Recipe memory can quickly change the production.
 Automatic round bottle circle labeling, symmetrical back and front labeling and fixed labeling of round bottle.
 Label teach function, one key to complete different label settings, intelligent and efficient
Specifications:
1. Labeling speed: 0-30m/min.
2. Labeling precision: ±1mm (excluding the package and label error).
3. Applicable paper roll internal diameter: 76mm.
4. Max paper roll external diameter: 300mm
5. Max label height: 200mm.
6. Applicable product size: h-25-350mm, w-20-100mm.
7. Applicable voltage: AC220V、50/60Hz.
8. Mechanical size: 3000x1500x1600mm

ROUND BOTTLE LABELING MACHINE

This machine is suitable for high speed labeling of round bottles in food, medicine and daily chemical industries.
For example: sauce, olive vegetable, condiment, edible oil, wine, fruit juice, honey, syrup, vitamins, capsules, bottled tablets, shampoo, bath lotion, cream and so on.
 Touch operation in English and Chinese on high resolution and large size of human-computer interface with control by PLC. With fault alarm display and help information, it’s intuitive and easy to use.
 Label sending system with emery roller technology, no wear no deformation, good friction without slipping to ensure labeling accuracy.
 Recipe memory can quickly change the production.
 Could according to the customer need to connect the production line, or buy feeding equipment.
 Optional: inkjet printer / coder, complete synchronization code labeling.
 Label teach function, one key to complete different label settings, intelligent and efficient
Specifications:
1. Labeling speed: 0-25 meters / min (60-150pcs).
2. Labeling accuracy: ± 1mm (excluding the package and label error).
3. Applicable paper roll internal diameter. 76mm.
4. Maximum roll diameter: 300mm
5. Voltage: 110V/220V, 50/60Hz.
6. Power: 1000W.
7. Mechanical size: 2000x850x1380mm

TURNING TABLE LABELING MACHINE

Hight speed Round bottle labeling machine.
70-120pcs/min or 120-300pcs/min
For round bottle circle label work.
